Menu 4-1-4 - Week Timers
Theentryscreenforconfigurationoftheweektimersofthesystemcentreiscalledusingthis
button. All important parameters and the status of the week timers are displayed there. Week timers can be
added using the "New entry" button. Already added inputs can be selected and configured using the
corresponding screen or deleted again.
Every week timer functions as independent week timer with up to 7 control times to which a switching output
and/or a passing contact can be assigned. The output is then active if the current time is within any of the 7
configured control times.
The screen contains the following parameters:
Week timers Input Default
Name Freely editable name / designation of the
week timer
max. 32 characters -
Control times
Start Week timer start 00:00..23:59 08:00
End Week timer end 00:00..23:59 4:00 PM
XXXXXXXXX Weekdays and groups of days Mon-Fri
Mon-Sat
Mon-Sun
Sat-Sun
Mon, Tue, Wed,
Thu, Fri, Sat, Sun
Mo-Fr
Switching contact and/or
passing contact
1)
Module
Module
1)
to which the output is connected
SIOX1 ..SIOX4 -
Submodule XX
Submodule
1)
to which the output is
connected; this is
ONLY visible if module=DDC1..DDC4 has
been selected
1..4 -
Output XX
Output
1)
to which the output is connected
1..12 -
Status XX Current status of the output:
Not active: = light grey
Active= green
- -
1)
Designationsofthesupportedmodules/outputs:
SIOX1 1st extension module, outputs 1 .. 8
SIOX2 2nd extension module, outputs 1 .. 8
SIOX3 3rd extension module, outputs 1 .. 8
SIOX4 4th extension module, outputs 1 .. 8
DDC1 1st GLT DDC module 1
DDC2 2nd GLT DDC module 2
DDC3 3rd GLT DDC module 3
DDC4 4th GLT DDC module 4
Only those SIOX modules and GLT PLC modules are provided for selection that have been configured
accordingly in screen 4-1-1! A description of the functions can be found in chapter Relay outputs for
week timers.
