Unit Only for pulse meters:
Selection of the unit of measure to be displayed.
Only for M-bus meters:
cannot be edited
kWh, l -
Primary address Only for M-bus meters:
the M-bus has an address range of 1..255. The M-bus
meters are identified via the primary address. The
primary address must be configured in the meter.
Therefore, a unique address must be allocated during
first start-up that may only be used once on the M-bus.
Practical tip: Most M-bus meters have the primary
address "0" as factory setting and are not found and
listed by the system centre. It is recommended to label
the M-bus meter with the primary address after the
configuration.
Power calculation Only for M-bus meters:
This activates the power calculation for the meter that is
required for the display of the load profile of the meter
(see Menu 6-2 - Load Profile). The power calculation is
deactivated at the factory.
Practical tip: No battery-buffered M-bus meter may be
used for continuous recording and for the Energy
management.
Meter input or
tariff input
Module
Module
1)
to which the measuring point is connected
SIOX1 ..SIOX4 -
Submodule XX
Submodule
1)
to which the measuring point is
connected; this is ONLY visible
if module=DDC1..DDC4 has been selected
1..4 -
Input XX
Input
1)
to which the measuring point is connected
1..12 -
Status XX Current status of the measuring point: - -
Legend for the meter symbols used:
power, water, gas, heating, cooling, oil and event
