9.1.5 Overview of the menu tree
Main menu Submenu 1 Submenu 2 Submenu 3 Menu number
1 Alarms and messages 1 - Alarms and messages
Current alarms
Message list
- - 1
2 System overview 2 - Overview and monitoring of the system (read-only!) 2
1 - Node overview Node overview - 2-1
2 - Case controllers Case controller overview Detailed information 2-2
3 - Pack controllers Overview of pack controllers Detailed information 2-3
4 - Receiver module
wireless sensors
Overview of receiver module
wireless sensors
Detailed information 2-4
5 - Other LDS
components
Overview of other components Detailed information 2-5
6 - EU archive Overview of EU archives Detailed information
EU archive (HACCP)
2-6
7 - Signal inputs Overview of signal inputs - 2-7
8 - Special inputs Overview of special inputs - 2-8
9 - General information - - 2-9
10 - Log - - 2-10
3 24h list
Overview of 24h list Temperature data of a
refrigeration point
- 3
4 Configuration 4 - Configuration System 4
Configuration Configuration System 4-1
1 - System Centre 1 - Configuration System centre configuration 4-1-1
2 - Signal inputs Signal inputs 4-1-2
3 - Special inputs Special inputs
-shuntlock
- emergency power
operation
- sprinkler alarm
- store lighting
- setpoint toggle
4-1-3
4 - Week timers Week timers 4-1-4
5 - Interfaces Interfaces
- COM1/Modem
- COM2
- COM3/MODBUS
- COM4
- Ethernet
- USB
4-1-5
6 - Measuring points Measuring points 4-1-6
The user must first be logged in at the system centre, see chapter Login to the system centre
(unlocking), to be able to make changes to the system centre or to E*LDS components
