7 System centre and SIOX connection / terminal assignment
System centre terminal diagram
SIOX extension module terminal diagram
7.1 System centre terminal diagram
The following figure shows the system centre in its complete design:
The detailed description of the connection and terminal assignments of the system centre and its components
is shown on the following pages.
DANGER
Warning about dangerous electrical voltage! In order to guarantee reverse polarity protection, only
coded mating connectors may be used on the control component connections.
