ECKELMANN VSC 5110 User Manual



Firmware V7.16.x
16.05.2023
21/183
•
•
•
•
4.2 Expansion stages of the Virtus 5 series
On the hardware side, the controller is always supplied in the complete design; on the software side, the
individual expansion stages and the associated range of functions are enabled using a licence key, see chapter
Menu 4-1-12 - System Upgrade.
Functions VSC 5010 VSC 5110 VSC 5410 VSC 5510
(complete design)
One CAN bus segment (connection to CAN1
terminal)
Support for up to 99 case controllers, 9 pack
controllers and 4 receiver modules
X X X X
USB Slave / Master X X X X
S0 meter, M-bus meter X X X X
Replacement for CI 3000 (2, 6, 16 MB) / CI
4000 / CI 4100
without connected compact
controllers
without LAN / Combi gateway
X X X X
Load shedding manager and water stop X X X X
BCT (building control technology) X X X X
Replacement for CI 3000 (2, 6, 16 MB ) / CI
3100 (6, 16 MB) / CI 4000 / CI 4100
with connected compact controllers,
Modbus interface for UA 30 Rx
compact controller / LDS1 gateways /
Dixell
withoutLAN/Combigateway
X X X X
Interface for Wurm / Danfoss third party
controllers
X X X X
Ethernet/LANinterface
Replacement for
- CI 3000 / CI 3100 Store Computer with LAN /
Combi gateway
-SystemcentreCI4400/CI5400withLAN
IMPORTANT:LAN/Combigatewaymustbe
removed from the E*LDS system!
Details for the exchange, repair and
replacement of a CI 3x00 store computer can
be found here.
X X X X
Two CAN bus segments (connection to
terminals CAN1 and CAN2)
with repeater function
Replacement for
- System centre CI 4500 / CI 5500
- X - X
Interface to the Virtus Caelum Apps - - X X
