6.2 DIN rail mounting - SIOX Extension Module
SIOX Extension Module: without manual control switch / with manual control switch
A maximum of 4 SIOX (Serial IOExtension) extension modules can be connected to the system centre. The
modules are connected to the system centre via SIOX power supply cables and SIOX data cables; see chapter
SIOX - connection to the system centre. Each SIOX module extends the system centre by an additional 8 relay
outputs and 12 digital inputs. The number of connected SIOX modules must be parameterised in menu 4-1-1.
The SIOX modules are available in two versions:
without manual control switch
with manual control switch to be able to switch the relay outputs manually
SIOX operating instructions
Comprehensive details on the SIOX extension modules and their current operating instructions can be
found here:
https://edp.eckelmann.de/edp/lds/_S88KwDvR7a
