2.Fileuploadofthefirmware
Requirements for performing the firmware update
-AccesstotheVirtus Control Desk of the system centre, e.g. via LAN connection or via USB slave, see
chapter Configuration of the E*LDS system using Service PC on site.
- Current firmware on the computer at https://edp.eckelmann.de/edp/lds/_qdCE7mLLnp.
Execution of the firmware update locally on site
fordetails,seechapterRemote control via Virtus Control Desk in the Firmware section.
3.LocallyonsiteusingaUSBstick
Requirements for performing the firmware update:
The new firmware must be available; this is usually provided as a compressed ZIP archive, e.g. at https://
edp.eckelmann.de/edp/lds/_qdCE7mLLnp.
The ZIP archive (it contains the directory "CI4000") must be unpacked using a PC into the root directory of a
USB stick (1 GB .. <=16 GB with 1 GB free space)
The USB stick for the firmware update and the configuration data must be formatted with FAT32 as file
system!
The requirements are met if the unpacking and copying to the USB stick has taken has taken place as
follows:
The directory, e.g. F:\CI4000 exists on the USB stick (if "F" is the drive letter for the plugged-in USB stick).
Execution of the firmware update locally on-site:
Fordetails,seechapterMenu 4-1-9 - Firmware Update
Practical tip
After performing the firmware update, check whether the desired firmware version has been
successfully installed (menu 4-1-9 or Info field in the main menu).
