Eclipse AVN5510 - Information Function; Information Screen

126
Information function
1. Information screen
The information function contains "SETTING", "ESN" and "SYSTEM CHECK". The "CAMERA
SCREEN" and "SIRIUS ID" function can be operated by installing the optional items.
Information screen
Press and then touch to display the INFORMATION screen.
Touch the touch switch.
• Select an item.
• The following functions are possible
from the information screen.
Display order/item (touch switch) Function Page
1 CAMERA SCREEN Display of Rear View Camera 128
2 SETTING
Settings for the background,
beep, etc.
OPERATION GUIDE/
Audio
Setting for Rear View Camera 132
3ESN
Settings for the ESN
(ECLIPSE Security Network)
OWNER'S MANUAL
4 SYSTEM CHECK Display of system status 127
5 SIRIUS ID Display of the SIRIUS ID
OPERATION GUIDE/
Audio
MENU
INFO
CAMERA SCREEN button is available when backeye camera (BEC106) is conneted.
