Eclipse AVN5510 User Manual
5
of 1
of 1 rating
167 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
54
4.
Ho
w to retrieve maps
Basic operation
T
ouc
h .
•
A POI list screen co
ntaining names sear
ched for from th
e entered characters i
s
displayed.
T
ouch th
e POI name to be display
ed.
•
T
ouch
to return to scr
een
on
"Retrievin
g a map using a POI name"
(Page 52).
•
T
ouch
to indicate the type o
f POI to be displa
yed on the POI li
st screen.
(Refer to page
55)
List
Name
Category
53
55
Table of Contents
Default Chapter
2
Table of Contents
2
Introduction
8
How to Use this Manual
8
Features
10
GPS Navigation System
14
How to View the Navigation Screen
14
Gps
16
Situations When GPS Signal Reception Is Impossible
16
Basic Operation
18
Menu Screen and List Screens
18
Menu Screen
18
How to Switch the List Screens
20
Up/Down Switch Display
20
Page Switch Display
20
POI Switch Display
20
Adjusting the Screen and Setting the Sound
21
Screen Adjustment
21
How to Display the Image Quality Adjustment Screen
21
Contrast/Bright
22
How to Switch to Daytime Display When the Lights Are on
22
How to Turn the Screen off
22
Switching the Map Display Color
23
Switching the Clock Display
23
Switching Miles and Km Display
24
Switching the Time Zone
24
Setting the Daylight Saving Time
25
Setting the Volume
26
Adjust the Volume
26
Set the Automatic Highway Volume Switch Function
26
Map Displays
27
Present Location Display
27
Moving the Map (One-Touch Scroll)
28
Moving the Map
28
Setting the Street Name Display While Scrolling
29
Switching the Touch Switch Display
29
Setting Touch Switches to Display or Not Display
30
Switching the Map Reduction Scale
31
Switching to the Desired Reduction Scale
31
Displaying City Maps
32
Switching to City Map Display
32
Canceling the City Map Display
32
Displaying the Building Data
33
Switching the Building Shape Display
33
Switching the Map Orientation
34
Switching to Double Screen Display
35
Operating the Screen on the Right
36
Canceling the Double Screen Display
37
POI Display
38
Display Landmarks by a Simple Operation While Driving
40
Delete a POI Landmark
40
Displaying Multiple Types
41
Search for POI Vicinity
42
Displaying a List of Pois Along the Set Route
44
Displaying POI Information
44
Setting the Type of POI Vicinity to be Retrieved While Driving
45
How to Retrieve Maps
47
Changing the Search Area
49
Retrieving a Map Using an Address
50
Retrieving a Map Using a POI Name
52
If Narrowing down Candidates Per Area
53
When Narrowing down the List by POI Type
55
Retrieving a Map in the Event of an Emergency
58
Retrieving a Map Using a Memory Point
58
Retrieving a Map Using the Archive
59
Retrieving a Map Using an Intersection Name
59
Retrieving a Map Using a Freeway Exit/Entrance Name
61
Retrieving a Map Using the Latitude/Longitude
62
Performing Operations on a Retrieved Map
63
Performing Operations on a Displayed Map
63
Displaying POI Information
63
Navigation Guidance
64
Setting the Destination and Searching for a Route
64
Set a Destination and Search for a Route
65
Setting a Destination
66
One-Touch Setting
66
Set from a Registered Point
67
Set Using the Map Retrieval Method
67
Route Search
68
All-Route Display
69
Route Displays
69
All-Route Display and Touch Switches
70
Display or Bypass a Restricted Segment
72
Bypassing a Restricted Segment
72
How to Display Message on a Restricted Segment
73
Display Route Data (Guided Road Information)
74
3-Route Simultaneous Display (3-Route Search Function)
75
Changing the Search Result Route
76
Adding a Destination
77
Change the Search Conditions for each Interval
79
Switching the Destination Order
80
Deleting a Destination
81
Indicating a Transit Road
82
Canceling a Transit Road Indication
83
Starting, Pausing and Restarting Route Guidance
85
Starting Route Guidance
85
Pausing and Restarting Route Guidance
85
Route Guidance
86
Intersection Guidance
86
A Non-Junction Intersection
86
A Junction Intersection (Enlarged Guidance Screen for an Intersection)
86
Set Automatic Display of the Intersection Guidance Screen
88
Canceling the Intersection Guidance Screen
88
Ferry Crossing Guidance
89
Setting the Required Time Display
89
Setting the Average Speed
90
Highway Junction Guidance
91
Canceling the Highway Junction Guidance Screen
91
Switching the Highway Junction Guidance Screen
92
Voice Guidance
93
Setting the Auto Voice Guidance
94
Performing Operations on the Guided Route
95
Guidance in Another Mode
95
Setting the Guidance When in Another Mode
95
Redisplaying the All-Route Display
95
Switching the Required Time/Distance Remaining Display
96
On-Route Scroll
97
Start On-Route Scroll
97
On-Route Scroll Screen Operations
97
Reinitiating a Route Search
98
Reinitiating a Route Search
100
Automatic Reroute Search
101
Setting the Automatic Reroute Search
101
Point Registration
102
What Is Point Registration
102
Registering, Correcting or Deleting a Memory Point
103
Registering, Correcting or Deleting Your Home
103
Registering Your Home
103
Correcting Your Home
105
Deleting Your Home
106
Registering Memory Points
107
One-Touch Registration
107
Registering a Far Away Point
108
Correcting the Position of a Memory Point
111
Changing the Symbol of the Memory Point
112
Enter a Telephone Number for a Memory Point
113
Entering the Name of a Memory Point
114
Displaying the Name of a Memory Point
115
Deleting a Memory Point
116
Registering, Correcting or Deleting a Special Memory Point
117
Registering a Special Memory Point
117
Correcting a Special Memory Point
119
Deleting a Special Memory Point
120
Registering, Correcting or Deleting Detour Memory Points
121
Registering Detour Memory Points
121
Correcting a Detour Memory Point
123
Deleting a Detour Memory Point
124
Destination Archive
125
Deleting Entries from the Destination Archive
125
Information Function
126
Information Screen
126
SYSTEM CHECK Screen
127
Optional Function
128
Rear View Camera Operations
128
Rear View Camera Image
130
Displaying the Rear View Image Manually (MANUAL)
130
Displaying the Rear View Image in Reverse Gear (AUTO)
130
Rear View Camera Settings
132
Helpful Tips
134
Correction of the Present Location and Distance
134
Present Location Correction
134
Correcting the Distance
136
Map DVD-ROM Data
137
Map DVD-ROM Data Display
137
Accuracy and Error
138
Positioning Accuracy
138
GPS Signal Quality and Reception Conditions
138
Present Location Display Error
140
Error Due to Having Changed a Tire
140
Correcting the Map Matching Vehicle Position Sensor
140
Present Location Display, Route Guidance Accuracy
141
Road and Geographic Name Data
143
Route Guidance
143
Information You Should Know
146
If One of These Messages Appears
146
Messages Related to General Navigation
146
Before Asking for Repairs
149
Items Related to General Navigation Functions
149
Copyright
150
End User License Agreement
154
Glossary
159
Index by Topic
161
Information about the Maps
161
Route Guidance
162
Others
164
Index
166
