DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual Measurement Accuracy
- 208 -
Appendix IV: Measurement Accuracy
Parameter Range Accuracy
Image depth range
C363UA: 19 mm ~ 245 mm;
L743UA: 29 mm ~ 108 mm
<±4% of full scale
M mode time range
C363UA: 3.99 s~ 48.1 s;
L743UA: 1.24 s~36.3 s
<±0.3% of full scale
TI
\
< ± 10%
Two-dimension Measurement
Distance/depth up to 250 mm < ±4% or < 2 mm, if below 40 mm
Area (Trace) up to 720 cm
2
< ±8% or < 130 mm
2
, if below 1600 mm
2
Area (Ellipse) up to 720 cm
2
< ±8% or < 130 mm
2
, if below 1600 mm
2
Angle 0º to 180º < ±3% on 1/2 segment
Ratio (A>B)
-Result B/A and (A-B)/A
-Result A/B
up to 1.0
1.0 to 99.9
< ±10% of A
< ±10% of A
Time Motion (TM) Measurement
Depth up to 250 mm < ±4% or < 2 mm, if below 40 mm
Time up to 12.8 sec < ± 5%
Heart rate 15 to 999 bpm < ±5%
Velocity (ratio) up to 999 mm/sec < ±5%
Volume Measurement
Volume (area, length,
diameter)
up to 999 cm
3
< ±12% or <8000 mm
3
, if below 64000 mm
3
Thyroid gland volume up to 999 cm
3
< ±12% or <8000 mm
3
, if below 64000 mm
3
Residual urine volume up to 999 mL < ±12% or <8000 mm
3
, if below 64000 mm
3
Prostate volume up to 999 cm
3
< ±12% or <8000 mm
3
, if below 64000 mm
3
PW measurement
Velocity
5 ~ 480 cm/s
< ±10%
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual EMC Information
- 209 -
Appendix V: EMC Information-Guidance and
Manufacture’s Declaration
Guidance and manufacture’s declaration-electromagnetic emissions-
For all EQUIPMENT and SYSTEMS
NOTE:
To protect from EMI, please leave the DUS 60 system away from the EMI sources. For
the technical reasons, electromagnetic immunity is limited to 1 Vrms, otherwise, the
interfaced images may affect the diagnosis and measurements.
Guidance and manufacture’s declaration-electromagnetic emission
The DUS 60 is intended for use in the electromagnetic environment specified below; The customer or
the user of the DUS 60 should assure that it is used in such and environment.
Emission test Compliance Electromagnetic environment-guidance
RF emissions
CISPR 11
Group 1 The DUS 60 uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely
to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class A
Harmonic emissions
IEC 61000-3-2
Class A
Voltage
fluctuations/flicker
emissions
IEC 61000-3-3
Complies
The DUS 60 is suitable for use in all establishments, other
than domestic and those directly connected to the public
low-voltage power supply network that supplies building
used for domestic purposes.
Guidance and manufacture’s declaration – electromagnetic immunity –
for all EQUIPMENT and SYSTEMS
Guidance and manufacture’s declaration – electromagnetic immunity
The DUS 60 is intended for use in the electromagnetic environment specified below. The customer or the user of DUS 60
should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level
Electromagnetic
environment -guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood,
concrete or ceramic tile. If
floor are covered with
synthetic material, the
relative humidity should be
at least 30%.
