DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Control
- 36 -
Twins
Small parts 1
Small parts 2
Gynecology
Orthopedics
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Control
- 37 -
Cardiology
Urology
Figure 5-4 Body Marks
5.4.7. Imaging Functions
B mode Imaging Control
Press this key to enter the B mode. The system displays a single real-time B mode image.
B indicates brightness, or two-dimensional (2D) gray scale imaging.
NOTE:
To return to a real-time B mode image from any imaging mode, press B control. This also
deletes all measurements, calculations, comments, or body marks that are displayed on
the screen.
2B mode Imaging Control
This key has two functions:
 Press this key to enter the 2B mode.
 Press this key to activate one of the dual images. The probe direction of the activated image
is brighter than that of the frozen image.
