DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Control
- 44 -
Figure 5-11 Preset Menu (the left—with no DICOM installed, and the right—with DICOM installed)
2. Roll the trackball to highlight one of the options and then press Set to display the menu of the
corresponding option.
To exit presetting:
Highlight Return and press Set. Then the system restarts automatically. The system runs with the
new modified parameters after being restarted.
5.7.2. Displaying / Modifying Presetting Parameters
Select a type of preset and press Set to display the corresponding dialog box, and you can modify
the parameter following the prompt instruction.
Reference
Section 5.6, Dialog box operation.
5.7.3. General Presetting
1. In preset menu, move the cursor to highlight General and press Set to display general
presetting dialog box, as shown below.
2. Roll the trackball to highlight an item and then press Set. Then use the keyboard to enter text.
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Control
- 45 -
Figure 5-12 General Presetting Dialog Box
Item Setting Allows you to
Hospital
Name
Input freely
Set hospital name displayed on the
key top left of the screen and
diagnosis report, with a maximum of
32 characters.
Default
Exam
Abdomen, obstetric, small parts, gynecology,
orthopedics, cardiology, urology, or vascular.
Preset the examination type.
Language
Chinese, English, etc.（The language options
vary with language software installed.）
Set the overlay language
Video Mode
PAL/N TSC
Set the video mode
SnapShot
Type
BMP/JPG/FRM/DCM (if DICOM is installed)
Set the storage file format type of
snap shot.
Keyboard
Sound
√/ Null
Turn on or off the keyboard sound.
Report
Printer
DJ 3600, DJ4100, DJ Generic VIP, LJ Mono
Select the printer type, see table 5-5
for the corresponding printer model.
Print Report
Select whether to print image in report.
Select whether to print image in report
when using USB printer.
Date
Format
Set freely
YYYY/MM/DD, MM/DD/YYY or
DD/MM/YYYY.
