EDAN DUS 60 - Configuration; Standard Configuration; Options

DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Overview
- 12 -
2.2. Configuration
2.2.1. Standard Configuration
 1 DUS 60 main unit
 1 convex array probe: C363UA
 1 power cord (European Standard)
 1 potential equalization conductor
 1 cable holder
 2 pieces of fuse, φ5×20, T3.15AL/250V
 1 Netac U disk, U180 (2G)
 1 bottle of coupling gel, 250 mL
 1 user manual
 2 packing lists
2.2.2. Options
The Digital Ultrasonic Diagnostic Imaging System supports the following options:
 Linear array probe: L743UA/L742UA/L763UA
 Endorectal probe: E743UA
 Convex array probe: C343UA/C362UA
 Micro-convex probe: C321UA/C613UA
 Endocavity probe: E613UA
 Ultrasonic Imaging Management System UMS 100
 Rechargeable lithium-Ion battery
 Printers are as shown below.
Printer type Recommended Models
Video printer
SONY UP-895MD, SONY UP-897MD,
MITSUBISHI P93W, MITSUBISHI P95W
USB printer
HP DeskJet D2368, HP DeskJet D2568
HP DeskJet D5568, HP LaserJet P2015, HP LaserJet P2035
HP Deskjet f2418*, HP Deskjet f2488*, HP2010, HP2050, HP1050
Table 2-1 Printers
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual System Overview
- 13 -
NOTE：Calibration should be performed because HP2418
*
and HP2488
*
printers will print
out calibration paper every time after replacing jet box, Please perform the calibration
according to the operation method on the calibration paper.
The video printer output: 110 mm× 82 mm; The USB printer output: A4 paper, 210 mm× 297 mm
 Freeze footswitch
 Mobile trolley MT-805
 Hand carried bag
 DICOM 3.0
