DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual Obstetric Measurements and Calculations
- 88 -
7.1.6. FL
To measure FL:
1. Press Measure to activate obstetric measurement.
2. In the obstetric menu, roll the trackball to highlight the menu FL, press Set, and move the
cursor to image and display “+”.
3. Measure FL, in the method of distance measurement.
Reference Section 6.6.1, Generic Measurements in B Mode
4. The results are displayed in measurement result window.
5. To begin a new FL measurement, repeat steps 1 through 3. You can measure a maximum of
one group of data.
7.1.7. AFI
To measure AFI:
1. Press Measure to activate obstetric measurement.
2. In the obstetric menu, roll the trackball to highlight the menu AFI, press Set, and move the
cursor to image and display “+”.
3. Measure four groups of AF, in the method of distance measurement.
Reference Section 6.6.1, Generic Measurements in B Mode
4. The results, AF1, AF2, AF3, AF4, and AFI are displayed in measurement result window.
5. To begin a new AFI measurement, repeat steps 1 through 3. You can measure a maximum of
one group of data.
7.1.8. TAD
To measure TAD:
1. Press Measure to activate obstetric measurement.
2. In the obstetric menu, roll the trackball to highlight the menu TAD, press Set, and move the
cursor to image and display “+”.
3. Measure TAD, in the method of distance measurement.
DUS 60 Digital Ultrasonic Diagnostic Imaging System User Manual Obstetric Measurements and Calculations
- 89 -
Reference Section 6.6.1, Generic Measurements in B Mode
4. The results are displayed in measurement result window.
5. To begin a new TAD measurement, repeat steps 1 through 3. You can measure a maximum of
one group of data.
7.1.9. APAD
To measure APAD:
1. Press Measure to activate obstetric measurement.
2. In the obstetric menu, roll the trackball to highlight the menu APAD, press Set, and move the
cursor to image and display “+”.
3. Measure APAD, in the method of distance measurement.
Reference Section 6.6.1, Generic Measurements in B Mode
4. The results are displayed in measurement result window.
5. To begin a new APAD measurement, repeat steps 1 through 3. You can measure a maximum
of one group of data.
7.1.10. CER
To measure CER:
1. Press Measure to activate obstetric measurement.
2. In the obstetric menu, roll the trackball to highlight the menu CER, press Set, and move the
cursor to image and display “+”.
3. Measure CER, in the method of distance measurement.
Reference Section 6.6.1, Generic Measurements in B Mode
4. The results are displayed in measurement result window.
5. To begin a new CER measurement, repeat steps 1 through 3. You can measure a maximum of
one group of data.
