Chapter 11
| Interface Commands
Transceiver Threshold Configuration
– 445 –
â—† Trap messages enabled by the transceiver-monitor command are sent to any
management station configured by the snmp-server host command.
Example
The following example sets alarm thresholds for the transceiver temperature at
port 1.
Console(config)interface ethernet 1/1
Console(config-if)#transceiver-threshold temperature low-alarm 97
Console(config-if)#transceiver-threshold temperature high-alarm -83
Console#
transceiver-threshold
tx-power
This command sets thresholds for the transceiver power level of the transmitted
signal which can be used to trigger an alarm or warning message. Use the no form
to restore the default settings.
Syntax
transceiver-threshold tx-power {high-alarm | high-warning | low-alarm |
low-warning} threshold-value
no transceiver-threshold tx-power
high-alarm – Sets the high power threshold for an alarm message.
high-warning – Sets the high power threshold for a warning message.
low-alarm – Sets the low power threshold for an alarm message.
low-warning – Sets the low power threshold for a warning message.
threshold-value – The power threshold of the transmitted signal.
(Range: -4000 - 820 in units of 0.01 dBm)
Default Setting
High Alarm: 1.50 dBm
HIgh Warning: -1.50 dBm
Low Warning: -7.30 dBm
Low Alarm: -11.30 dBm
Command Mode
Interface Configuration (SFP/SFP+ Ports)
Command Usage
â—† The threshold value is the power ratio in decibels (dB) of the measured power
referenced to one milliwatt (mW).
â—† Refer to the Command Usage section under the transceiver-threshold current
command for more information on configuring transceiver thresholds.
