4.6 Alarm Setup and Alarm Activation
Please note simple lite series product does not support the alarm function.
Before operation, please make sure you have properly connected alarm devices such as light,
buzzer.
4.6.1 Go to alarm setup interface
In the main menu, from Setting to Alarm, you can see alarm setup interface. See Figure 4-24.
4.6.2 Alarm setup
Alarm interface is shown as below. See Figure 4-24.
Alarm in: Here is for you to select channel number.
Event type: There are two types. One is local input and the other is network input.
Type: normal open or normal close.
PTZ activation: Here you can set PTZ movement when alarm occurs. Such as go to preset, tour&
pattern when there is an alarm. Click “select” button, you can see an interface is shown as in
Figure 4-25.
Period: Click set button, you can see an interface is shown as in Figure 4-26. Here you can set for
business day and non-business day. In Figure 4-26, click set button, you can see an interface is
shown as in Figure 4-27. Here you can set your own setup for business day and non-business day.
Anti-dither: Here you can set anti-dither time.
Show message: System can pop up a message to alarm you in the local host screen if you enabled
this function.
Alarm upload: System can upload the alarm signal to the network (including alarm center) if
you enabled current function.
Send email: System can send out email to alert you when alarm occurs.
Record channel: you can select proper channel to record alarm video (Multiple choices). At the
same time you need to set alarm record in schedule interface (Main Menu->Setting->Schedule)
and select schedule record in manual record interface (Main Menu->Advance->Manual Record).
Latch: Here is for you to set proper delay duration. Value ranges from 10 to 300 seconds. System
automatically delays specified seconds in turning off alarm and activated output after external
alarm cancelled.
Tour: Here you can enable tour function when alarm occurs. It is a one-window tour: Please go to
chapter 5.3.9 Display for tour interval setup.
Buzzer: Highlight icon to enable this function. The buzzer beeps when alarm occurs.
For snapshot operation, please refer to chapter 4.4.2.
Please highlight icon to select the corresponding function. After setting all the setups please
click save button, system goes back to the previous menu.
