Click this button, system goes back to the single screen mode. Drag the mouse in the screen to adjust
section size.
Figure 6-4
Here is a sheet for you reference.
Name
Function
key
function
Shortcut
key
Function
key
function
Shortcut
key
Zoom
Near
Far

Focus
Near
│
Far
►│
Iris
close

Open

6.2 Preset /Patrol / Pattern /Border Function
In X402H402H402HFigure 6-2X click the set button. The interface is shown as below:
Here you can set the following items:
 Preset
 Patrol
 Pattern
 Border
Figure 6-5
In X403H403H403HFigure 6-2X, click page switch button, you can see an interface as in X404H404H404HFigure 6-6X.
Here you can activate the following functions:
 Preset
 Tour(Patrol)
 Pattern
 Auto scan
 Auto pan
 Flip
 Page Switch
Figure 6-6
