Edwards ModuLaser User Manual

Chapter 3: Configuration and Commissioning
ModuLaser Modular Aspirating Smoke Detector Installation Manual 57
To configure inputs:
1. Select Device Settings from the Main menu, and then select Inputs.
2. Select the device that you want to view or press F1 (Go To) to search for a
device by the device address.
3. Select the input that you want configure, and then configure the Influence and
Function fields as required.
See Table 20 below for more information on input functionality.
4. Press F1 (Save) to save your changes and exit to the previous screen.
5. If you have no other configuration changes to make, then press F1 (Apply)
from the Main menu or the submenu to apply the changes to the system.
The configurable options for the input functionality are shown in the table below.
All inputs can be configured for Local or Cluster influence.
Table 20: Input functionality
Function
Description
Unused
The input is not used (this is the default setting).
Battery Check
When the input deactivates, the module generates a fault condition
(battery fault).
Mains Check
When the input deactivates, the module generates a fault condition
(mains voltage fault). The device or devices affected by the
configured influence enter power save mode (if configured to do so).
Remote Reset
When the input activates, the device or devices affected by the
configured influence are reset.
Remote
Disable When the input activates, the device or devices affected by the
configured influence are disabled.
Rem. Day/Night
[1] Remote Day/Night. When the input activates, the device or devices
affected by the configured influence are set to day mode. When the
input is deactivated, they are set to night mode.
[1] Only available for detector modules.
Notes
• When a function is enabled for a given input, any previous configuration using
that input is automatically disabled.
• An open circuit in an input will be indicated as an Input Open Circuit fault.
• Avoid configuring two or more inputs with the same functionality (this may
create conflicts).
• Inputs and input functionality for legacy devices may vary from those
described here. Refer to the corresponding device installation manual for
more information.
