107 Installation and Service Guide
Troubleshooting
Fan is:
• Properly positioned (not backwards)
• Installed in the correct connector
• Not visibly damaged (fan, fan cable, cable connector,
and motherboard connector)
Fans, page 74.
The power supply is:
• Present
• Correctly installed
• Not visibly damaged
Cable connectors are:
• Firmly connected
• Not visibly damaged
• Installed in the correct devices
Power supply, page 76.
The hard disk drive is:
• Present
• Correctly installed
• Not visibly damaged
Hard disk drive data cables are:
• Present
• Firmly connected to the correct SATA connectors on the motherboard
(see page 57)
• Not visibly damaged
Hard disk drive power cables are:
• Present
• Firmly connected to the SATA power connectors on the hard disk
drives.
• Not visibly damaged
Hard disk drive (3), page 78.
.
Each cable required is:
• Present
• Installed in the correct connector
• Well-seated
• Not visibly damaged (cable or connector)
HDD data cable, page 78.
Power supply cable, page 76.
If included in the system, the required mouse, monitor, and keyboard are
present and appear undamaged. The mouse and keyboard are connected
to the correct ports on the E-35A connector panel.
The cables required are:
• Present
• Installed in the correct connector
• Well-seated
• Not visibly damaged (cable or connectors)
For the following items, see the documentation that
accompanies the package.
• Mouse, page 21.
• Monitor, page 21.
• Keyboard, page 21.
• Monitor power cord.
Conditions to verify Part and additional page references
