Page #60 background image
60 Installation and Service Guide
Replacing Parts
All cables connected from other components to the motherboard.
These includes the motherboard power cable, CPU power cable, chassis fan cable, HDD data cable, 10-pin power
button cable,and Fiery QuickTouch power and USB cables.
To remove motherboard components from the motherboard
1 Access and open the E-35A (see page 49).
2 Remove the printer interface board (see page 56).
3 Remove the following cables attached to the motherboard:
Fiery QuickTouch USB cable
Hard disk drive (HDD) data cable
SATA data cable
Power supply cable
24-pin motherboard power cable
4-pin motherboard power cable
Fan cables (chassis fan and CPU fan)
For the location of each connector on the motherboard, see Figure 31 on page 59.
Important: Follow standard ESD precautions while handling the motherboard and all components. For details,
see“Precautions” on page 10.
