Printer Operations
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 107
1 Job Info Size: The width and length of the Job.
Resolution: Set by default, according to the
mode.
2 Print
Settings
Mode: Set by default, according to the mode. Cannot be changed.
Direction: Single or Bidirectional Printing. Can be changed before you print.
Speed: Available options depend on the Resolution and Mode. Can be changed before you print.
UV Mode: Depending on the direction of the carriage: Leader: the front lamp is lit.
Trail: the rear lamp is lit.
Both: both lamps are lit. This is the default setting. Can be changed before you print.
UV Power – Percentage of the lamp's total power to be used, defined from the UV Power Setting dialog box.
Can be changed before and during printing.
Actual Power – The actual UV power in numbers.
3 Options Noise: Choose from 1-6, only if the print mode allows it.
Double Strike: Doubles the density of the file for backlit printing, only if the print mode allows it.
Scale: To enlarge the Job's size.
Density: To adjust the CMYK density (all, or individual).
4 Double Side Off: One side printing
Backlit: Backlit printing.
Blockout: Blockout printing
Back side: to print the back side of double side.
50%: Set the print density to 50%.
5 Positioning Alignment: Aligns the file to the Left, right or center of the media.
Print Offset: Moves the image to the left/right with a set value.
Step & Repeat: Set number of horizontal and vertical copies. Only vertical copies can be changed during
print. If number of copies results in no gap between copies, there is no gap between newly inserted copies.
Gap: Insert a gap between images. This cannot be changed while printing a Job.
Mirror: Mirror Flip.
Rotate 180: Rotate 180º
6 In-line
Finishing
Cutter (optional): Activates the X cutter
Top/Bottom: The Job can be cut in its edge
(0), in Margins (Negative value) or in Bleed
(Positive value)
Slitter Marks: Activate to print Slitter Marks
Along Image: Print marks through the length
of the Job.
Left/Right: Locate slitter marks to slit job on its edge (0), in margins (negative
value) or in bleed (positive value)
7 Jobs Label Prints any of the following data on the job: File name, Copy #, Time, Mode, manually inserted information.
8 Media Location and width of the media roll(s).
Edit/Measure: Access to the Edit/Measure dialog box.
9 Roll Number Specify on which of the multi rolls you wish to print the Job.
10 Job State To put the Job on Hold or Waiting to be printed mode.
