Figure 3-22
Display
Control Buttons
Tension Knob
Hardware Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 42
Controls
• Arrows - Sets the tension
• Rev - Reverse
• Fwd - Forward
• Stop - Stops spinning
• Knob - Sets spinning speed
3.10 Roll Tension Control
