EFI Pro 32r - Pneumatic System Configuration

Hardware Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 32
3.4 Pneumatic System
Figure 3-12
Air Supply Port
Air Pressure Regulators
Five-Way Solenoid Valve
Main
Back
Infeed
Roller
Front
Outfeed
Roller
