Figure 3-23

Yellow1 + Cyan1

Magenta + Black

Yellow2 + Cyan2

White

Hardware Overview

Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 43

There are four purge buttons located at the front left

of the printer close to the carriage.

The back pinch roller button toggles the roller open / closed.

3.11 Purge Buttons

3.12 Rear Left Control Button

Figure 3-24
