Printer Operations
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 111
The following settings can be changed during printing:
Setting Can be changed in …
Nozzle Test
(Fire-all At Home Position)
The Control Panel
1. Pause the printer.
2. Purge and wipe the print heads.
3. From the Fire All dialog box, in the At Home Position,
choose the Fire button.
4. Choose OK.
Free-Fall Continuous Collec- The Control Panel (If the option is activated.)
Print Tension Power The Control Panel
Advance Fine Tuning The Control Panel
Calibrations The Control Panel
Printer Status The Printer Status dialog box (accessed by double-clicking the printer status bar, to the left of the
UV
Status indicator in the Control Panel).
Increase/Decrease UV Power The Printer Status dialog box
Image Position The Printer Status dialog box (Left – Right, forward –
backward).
Step & Repeat (in Y)
Specify
number of copies.
The Job Settings dialog box.
If you have specified a Gap, then it will appear in
subsequent copies.
Carriage Movement Margin The Preferences dialog box.
6.4 Changing Settings During Printing
