Hardware Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 40
The UV LED Curing system comprises two UV LED lamps, one at each side of the carriage.
Main features:
• Low electricity consumption
• Environmentally friendly
• Zero initialization time - immediately ready to work
• Runs at a low temperature, thus enabling printing on a vast range of media types, including heat sensitive media
Figure 3-20 Shown From Side of Carriage
Carriage
Ionizer
The ionizer, shown in Figure 3-20 neutralizes the
electrostatic charge that accumulates, and prevents
“mist” from accumulating on the media.
Figure 3-20 shows one of the printer’s two ionizers.
Each ionizer is located adjacent to a LED lamp unit, at
either end of the carriage.
3.7 UV LED Curing System
3.8 Ionizer (Anti-static Bar)
