Safety
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 14
This section lists and describes potentially hazardous items and areas. Care should be exercised when working with or
near these items and areas.
2.3.1 The Cable Carrier
The cable carrier carries all the cables and pipes between the PC / ink system and the carriage. During printing, the
carriage moves continuously along the chassis.
2.3.2 The Cover
The cover is located at the front of the printer; its function is to protect user from UV rays and from contact with the
moving carriage. It opens and closes manually.
2.3 Potential Hazards
Warning: Contact between the moving carriage and a foreign object can
cause injury and damage.
Cover - Closed
Figure 2-1
