Hardware Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 31
3.3.5 Ink System and Print Head Configuration
The Print Head configuration:
Figure 3-11
White
Yellow
+ Cyan
Magenta
+ Black
Black +
Magenta
Cyan +
Yellow
White
