EFI Pro 32r - Page 24

Hardware Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 24
The following figure shows the rear of the printer.
NOTE: The location of Printer parts assumes that the user is facing the Printer, whether at front, back, or sides.
Figure 3-3
Air Shaft
Air Shaft Control
Main Switch
Air Outlet
