Software Overview
Document ID: OMM-00165 Rev. C Pro 32r Operations Guide 74
13 Double-sided Print
• Head-to-Head/Head-to-Tail Printing Workflow
• Y Gap before image: Distance between the first printed
Backlit Registration Marks and the image along the Y-axis.
• X Gap from image: The distance between the printed
Backlit
Registration Marks and the image along the X-axis.
• Min X Correction: The minimum correction on the X axis
at
which the printer will correct the misalignment.
• Min Y Correction: The minimum correction on the Y axis at
which the printer will correct the misalignment.
• Swap Front/Back Marks: swaps the side of the media on
which the marks are printed.
• Blockout Label to Image: the distance between the
Blockout
label and the printed image
• Heads to Mark Distance: the distance between the print
heads
and the Backlit Marks.
• Short Measure: Only measures media location.
C
arried out
automatically between copies in Blockout printing.
14 Flatbed Mode
• There are three options in Flatbed Mode: Manual /
Autoloader / Vacuum Plate
• Stroke Mode – Relates to Autoloader only. To
accommodate
long media, the autoloader carries out the
Stroke procedure,
twice (Double Stroke). For regular
media length Single Stroke is
sufficient.
• Automatic – Back Pistons open and close automatically.
• Plate size – only relates to the Vacuum Plate and defines
the
size of the installed plate.
• Automatically raise Back Pistons.
• Vacuum Plate Auto-Init before print. When enabled,
the Vacuum Plate INITs before each print.
• Front Wing to Heads – The distance between the print
starting
point and the media’s edge.
• Gap before Image – Defines the gap between the edge of
the
media and the print starting point.
15 Automatic White Stirring: Periodically stirs white ink tanks. 16 Connecting the printer to the iPhone server, to enable the
iPhone application (optional).
