31
06/2011 - Art. Nr. 13 018 118C
Overview
Dimensional drawings and measurements
VGL 06.1200/1600/2100 DP
with gas valve MBVEF 412 and MBVEF 420
D
E
H
E
H
D
KL
KM
KN
KL
KM
KN
Space requirements
There should be a space of no less
than 0.8 metre on each side of the
burner for maintenance purposes.
Gas valve assembly
The valve assembly can be fitted on the
left or the right.
DEH
MBVEF 412 160 590 Rp2
MBVEF 420 690
