EKB3/
EKB3W
Yellow LED indicates system faults. LED indications are mentioned in the table below.
LED
Description
Steady ON One or more tampers are violated; other system faults (see below)
Flashing One or more high-numbered zones (Z13-Z76) are violated
In order to nd out more on the particular system fault, please enter command A provided below. After this procedure the system
will activate red zone LEDs for 15 seconds. The description on each LED indication is mentioned in the table below.
Zone LED Description
1 Mains power is lost
2 Low backup battery power - backup battery voltage is 10.5V or lower
3 Backup battery is not present or the battery voltage runs below 5V
4 Backup battery requires replacement - backup battery resistance is 2Ω or higher
5 Siren is disconnected/broken
7 One or more tampers are violated
8 Date/time not set
9 One or more high-numbered zones (Z13-Z76) are violated
10 GSM connection is lost
11 GSM/GPRS antenna is disconnected/broken
12 Wireless antenna is disconnected/broken
In order to nd out which particular high-numbered zone is violated, please enter command B.
In order to nd out which particular tamper is violated, please enter command C.
A. System fault indication - enter command:
B. Violated high-numbered zone indication – enter command:
1
C. Violated tamper indication – enter command:
2
The number of violated high-numbered zone or tamper can be calculated using the table below according to the formula: number
from zone LED section B + number from zone LED section A.
Example: LED #3 from section A is ashing and LED #8 from section B is steady ON. According to the table below LED #8 is equal
to number 18, therefore 18 + 3 = 21.
Result: Violated high-numbered zone or tamper number is 21.
Zone LED section - A (ashing) Zone LED section - B (steady ON)
Zone LED 1 = 1 Zone LED 7 = 12
Zone LED 2 = 2 Zone LED 8 = 18
Zone LED 3 = 3 Zone LED 9 = 24
Zone LED 4 = 4 Zone LED 10 = 30
Zone LED 5 = 5 Zone LED 11 = 36
Zone LED 6 = 6 Zone LED 12 = 42
