EKB2
1. Enter master code and navigate through the following menu path using OK and arrow keys to monitor and view the power
consumption:
Menu path:
Real-time power consumption: OK → mmmm → OK → PGM OUTPUTS → OK → out-name → OK → REAL TIME ENERGY
Today’s power consumption: ... → out-name → OK → TODAY ENERGY
Monthly power consumption: ... → out-name → OK → MONTHLY ENERGY
Value: mmmm - 4-digit master code; out-name - PGM output name associated with a certain EWM1 device
2. Enter master code, navigate through the following menu path using OK and arrow keys and select YES to reset the power
consumption counter of the selected EWM1 device:
Menu path:
OK → mmmm → OK → PGM OUTPUTS → OK → out-name → OK → RESET COUNTER → OK → YES | NO → OK
Value: mmmm - 4-digit master code; out-name - PGM output name associated with a certain EWM1 device
3. icon displayed in home screen view indicates presence of system and EWM1 device faults. Enter master code and navi-
gate through the following menu path using OK and arrow keys to view EWM1 device faults:
Menu path:
OK → mmmm → OK → PGM OUTPUTS → OK → out-name → OK → FAULTS → OK
Value: mmmm - 4-digit master code; out-name - PGM output name associated with a certain EWM1 device
Name Description
OVERVOLTAGE Voltage has increased above 260VAC.
UNDERVOLTAGE Voltage has dropped below 190VAC.
OVERCURRENT Current has increased above 12,5A
RELAY FAULT Unable to power up the appliance due to faulty relay
TEMP. FAULT Environmental temperature has dropped below -35°C (-31°F) or in-
creased above +90°C (+194°F)
In order to clear the existing faults, please press the button on EWM1, turn OFF the electrical appliance or turn OFF the wireless PGM
output associated with EWM1.
