Technical Support - MDM 21/97 599 76 11-68 Rev. 01
4.3.3 Control panel configuration
The washing programmes, the functions of the selector knob (where featured) and the various sensors
vary according to the model, since these are determined by the configuration of the appliance.
4.3.3.1 Programme selector (S1)
The selector used is of the HI-FI type (the dial has no index and no
reset position, the programme selected is indicated by the fact that the
corresponding LED lights up). The number of positions cannot be
configured. There are always 14 (in all styling) and they are bound to
the number of LEDs that indicate the washing programmes.
The programmes can be configured to perform different washing cycles
(e.g.: water level, drum movement, no. of rinses and the washing
temperature to be selected according to the type of garments).
The selector can be turned both clockwise and anti-clockwise.
For each programme, the compatible options and other parameters are
defined.
4.3.3.2 Programme configuration
The table below lists the parameters that can be used to define the washing programmes.
Cotton/linen, Synthetic fabrics, Delicates, Wool, Hand-wash,
Shoes, Jeans, Duvet, Silk.
Soak, Miniprogramme, Easy-Iron, Conditioner, Rinses,
Delicate rinses, Drain, Delicate spin, Spin.
Normal, Maximum: the initial temperature is the one set for the
washing programme selected.
Normal, Minimum, Maximum.
Options (Normal/Possible)
Rinse Hold, Night Cycle, Pre-wash, Stains, Extra Rinse, Easy-Iron,
Time manager 1/2/3/4/5/6/7/8, Reduced Spin Speed, No Spin.
Pre-wash, Wash, Rinses, Spin, Delayed start.
