Technical Support - MDM 73/97 599 76 11-68 Rev. 01
Remove the connectors with care, as some are held in place by hooks.
14.2.2 Main board EWX13611
To service the main board, use the antistatic kit a code 4055063-95/4.
Remove the worktop (see relevant paragraph).
Remove the power cable from the hooks that hold it close to the board.
Slide off the connector.
Unfasten the two screws securing it to the cabinet.
Remove the clamp that secures the wiring to the spring support bracket.
Using a pair of pliers, remove the clamps that secure the wiring to the power
board assembly container (indicated by the arrows).
