The washing unit is made up of:
A back casing (1) and a front casing (2), welded together to form the welded tub. Inside this is the drum (5)
(made of stainless steel) with the three blades (6) (in carboran) snap-fastened to the drum.
To balance the unit during the washing movements and during the spin phases, the counterweights are secured
in place with screws: one at the front (3) and one at the top (7).
The bellow seal (4) is fixed at the front.
The washing unit is suspended by two coil springs (8) attached to the top crossbar, and the oscillations are
dampened by two shock absorbers, one on the right (9) and one on the left (10) (looking straight at the front
of the appliance).
