Electrolux EWF1284EDW - EWM09312 Operating Circuit Diagram Key

Technical Support - MDM 68/97 599 76 11-68 Rev. 01
13.2 EWM09312 Operating circuit diagram key
Appliance electrical components
PCB components
1. Main electronic circuit board
2. Door safety interlock
3. Electronic pressure switch
4. NTC
5. Pre-wash solenoid valve
6. Wash solenoid valve
7. Universal motor
7a. Tachometric (motor)
7b. Stator (motor)
7c. Rotor (motor)
7d. Thermal cut-out (motor)
8. Heating element
9. Flowmeter
10. Display board
11. Aqua control sensor
12. Drain pump
DRAIN_YTY Drain pump Triac
DOOR_TY Door interlock Triac
PWELT_TY Pre-wash solenoid Triac
WELV_TY Wash solenoid Triac
K1 Heating element relay
K2 Heating element relay
