Electrolux R134A - Auto Damper Control Models

2-10
4. Remove the control housing mounting
screw at the back of the control hous-
ing. Slide the control housing to the
right and lower from control housing
supports.
5. Disconnect the temperature control
housing electrical quick disconnect.
6. Remove the temperature control hous-
ing from the refrigerator and place on a
flat work surface.
7. Remove the control knob by pulling it
away from the temperature control.
8. Remove the electrical and ground leads
from the temperature control terminals.
9. Remove the control by pushing on the
tab with right thumb to release the lock.
With the left hand, rotate the control out
of its locking tabs.
10. To remove the thermal mass, insert a
flat bladed screwdriver between the
thermal mass and the control housing
area. Turn the screwdriver to release
the mass from its locking tab.
11. Install the replacement control in the re-
verse order of removal.
AUTO DAMPER CONTROL
MODELS
The Auto Damper model refrigerator has
two controls and both have capillary sens-
ing. The Auto Damper controls the fresh
food temperature and the Freezer Tempera-
ture Control guides the freezer temperature.
The fresh food compartment temperature
is maintained by a damper assembly lo-
cated at the back of the temperature con-
trol housing. Changes in air temperature
cause the damper door to open and close.
A control rod and gear connect the fresh
food control knob to the damper control.
Turning the fresh food control knob to the
COLDEST position increases the flow of
freezer air into the fresh food section. The
freezer compartment temperature control
warms at a faster rate and cools at a slower
rate, increasing the compressor run time
necessary to maintain a satisfied freezer
temperature control.
Turning the fresh food control knob to a
WARMER setting decreases the flow of
chilled air into the fresh food section. The
freezer compartment temperature control
warms at a slower rate and cools at a faster
rate, decreasing the compressor run time
necessary to maintain a satisfied freezer
temperature control.
