3-5
Lift the door up enough to allow
another adult to guide the water
line through the hinge pin. Rest
door on a non-scratching surface.
Hinge
Pin
Mark the location of the bottom
hinge with a pencil. Use a 5/16"
socket & ratchet to remove the
3 screws from the bottom hinge.
Remove
3 Screws
Hinge
Pull Apart
Ground
Wire
Screw
Hinge
Screws
Door
Water
Line
Water Line
Connector
Water Line
To Cabinet
Push collet against
connector to release
the door water line
WATER/ICE FREEZER DOOR REMOVAL
To Next Page
