3-4
DOOR ALIGNMENT
The cabinet door on all models is in correct
alignment when:
1. The hinge side of the door is an equal
distance from the cabinet flange at the
top and bottom.
2. The gasket seals smoothly and is com-
pressed no more than 1/16" along the
hinge side with the door closed.
3. The door lines up with the side of the
cabinet (viewed from the front). The
door panel is parallel with the cabinet
top.
In many cases, leveling the refrigerator will
eliminate the need for cabinet door adjust-
ments. Ensure that the refrigerator is plumb
by checking all edges as well as both sides
of the cabinet with a carpenter's level.
DOOR SWITCH
Disconnect the unit from the power
source.
The door switches can be easily removed
by using a flat blade screw driver or putty
knife. Pry from the liner and disconnect
wires.
WATER/ICE DISPENSER FREEZER
DOOR REMOVAL
Before attempting to remove the door
hinge, look at your refrigerator and note the
exact number and position of all protective
shims on the door hinge. Later, when you
replace the hinge, these must be positioned
correctly.
1. Disconnect the unit from the power
source.
2. Open the door completely. Remove
the bottom hinge cover by squeezing
on the bottom and top while pulling it
toward you.
3. Locate the water line tubing coming out
of the cabinet. Carefully pull on the tub-
ing until the connector is on the outside
of the cabinet.
4. Disconnect the door water line tubing.
5. Remove the top hinge cover.
6. Disconnect the door wire harness by
pulling apart the two halves of the con-
nector. DO NOT PULL THE WIRES.
7. Mark the position of the top hinge with
a lead pencil.
8. Remove the ground wire screw with a
1/4" socket & rachet. Hold door with
one hand and finish removing screws.
Leave the hinge in the door.
9. Replace the door in reverse order of
removal.
