3-18

WATER FILTER AND ICEMAKER WATER TUBE

ROUTING ON THE BACK OF THE REFRIGERATOR

Water Filter Outlet

Water Filter Inlet

Icemaker Inlet

Filter

Valves

Water\Icemaker

Valves
