42. Drum with bearing
Service
manual
487 03 29 41
18
42
Removing Sliding Door equipment:
(continued from the previous page)
11.The support rail T is dismantled.
The front U is dismantled
12. After this, the procedures for dismantling
and installing the drum are exactly the
same as on a dryer with standard door,
as described earlier in this section.
• Note! When installing the side panels,
use 5 mm rivets
11
12
T
U
