487 03 29 41
17
42. Drum with bearing
Service
manual
42
Removing Sliding Door equipment:
(continued from the previous page)
9. Remove the top rivet in the side panel.
The panel is then swung out at the top
and secured with string as illustrated.
10. The slide rail Q is dismantled.
Continued on the following page
9
10
Q
