42. Drum with bearing
Service
manual
487 03 29 41
16
42
Removing Sliding Door equipment:
(continued from the previous page)
7. The top glass door is lifted up in the slide
rails and secured to the front with lock
grip pliers or clamps.
8. The bottom door can then be edged out
of the slide rails by pressing gently to the
right or left.
The top door is edged out in the same
way.
Continued on the following page
7
8
