487 03 29 41
3
43. Cabinet
Service
manual
43
1
2
555 mm
A
A
A
B
A
A
A
Sliding Door.
Adjustment of sliding doors
It is important that the 2 sliding doors are
parallel in order for the doors to close tightly,
fig. 1.
1. Disconnect the power supply to the dryer.
2. Adjust a board to 555 mm for fixation of doors.
• Place it between handle and girder B.
3. Loosen all 6 wire clamps A.
4. Check that the 2 sliding doors are closing
parallel.
5. Tighten the wire in all wire
clamps A, fig. 2.
Continued on the following page.
