Elmo Bassoon - Page 30

2
10
9
Bassoon
Feedback A
1
Hall C
Hall B
Tach o+
Tach o-
3
11
Encoder / Hall +5v Supply
Hall / Encoder Supply / Voltage Return4
HC
HB
Tac2+
Tac2 -
Tac1+
Tac1 -
+5V
SUPRET
BAS0035A
12
Hall AHA
6
Tach o+
Tach o-
Up to 20Vmax
Feedback Input
Up to 50Vmax
Feedback Input
Tachometer with
Hall Sensor
5
Figure
3-13: Main Feedback – Tachometer Feedback with Digital Hall Sensor Connection
Diagram for Brushless Motors
Figure
3-14: Main Feedback – Tachometer Feedback Connection Diagram for Brush Motors
Bassoon Installation Guide Installation
MAN-BASIG (Ver 1.4)
3-18
