2 PART NAMES AND FUNCTIONS
Appearance
Operation of the main unit:
Name
①
Camera head
②
Arm
③
Operating panel
④
Rear panel
⑤
Side panel
⑥
Bottom panel
⑦
Lamp
⑧
Microphone
P22
P13
P15
P18
P19
P25
⑥
④
①
②
③
⑤
⑦
⑧
