Elmo MO-1 User Manual

30
Descriptions of each menu
Camera output display mode menu
Icon
Name
Selection Item
Factory
Setting
Function
Preferences
To display the setting menu
for the camera image.
Thumbnails
To display thumbnails of
images saved in the SD
card.
Exit
To hide the menu.
Setting menu (Second layer)
Icon
Name
Selection Item
Factory
Setting
Function
Resolution
For HDMI
1080i

To set the HDMI output
resolution.
The resolution that the
connected display device
does not support cannot be
set.
*1 Suitable when shooting
moving objects.
*2 Suitable when taking
wide angle images.
720p 60fps
*1
720p 30fps
*2
Resolution
For RGB
WXGA
[WXGA]
To set the analog RGB
output resolution
Effective when the output
resolution setting switch on
in the bottom panel is set to
[MENU].
XGA
[XGA]


Elmo MO-1 Specifications

General

Product color	Pink
Built-in microphone	Yes
Sensor type	CMOS
White balance	Auto, Manual
Optical sensor size	1/3.2 \
Effective sensor resolution	5 MP
Supported graphics resolutions	-
Digital zoom	8 x
Shooting area (WxD)	257 x 342 mm
VGA (D-Sub) input ports	1
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, USB

Weight and Dimensions

Depth	226 mm
Width	101 mm
Height	338 mm
Weight	550 g
Dimensions folded (WxDxH)	101 x 226 x 28 mm
