Switching the output video
The Video Output LED of the output terminal used is lit.
The output video can be selected by pressing the Image Selection button.
Video Output
LED
Function
①
HDMI
A video signal is output from the HDMI OUT terminal.
②
RGB
A video signal is output from the RGB OUT terminal.
③
USB
The product can be connected to a PC via a USB cable.
④
EXIT
In standby status (power is OFF)・the AC Adaptor is used
(*1):
A video signal input to the RGB IN terminal is output from
the RGB OUT terminal.
In operation (power is ON)・the AC Adaptor is used:
A video signal input to the HDMI IN terminal is output from
the HDMI OUT terminal(*2)：
A video signal input to the RGB IN terminal is output from
the RGB OUT terminal.
