Elmo MO-1 User Manual

40
9 SPECIFICATIONS
General
Item
Specifications
Power source
DC5V（AC adapter AC100～240V）
PC requirements for the power supply from a USB:
- A PC with the USB3.0 port
- A PC with 2 USB ports
Refer to P22 for details about the connection procedure.
Power consumption
4.2W(DC5.0V)
(USB Power Supply：3.3W)
Outside dimensions
W101×D416×H338［mm］（When setup）
W101×D 行 226×H28［mm］（When folded）
Weight
Approx. 550g
Output terminal
RGB output Mini Dsub 15P connector female×１
HDMI output TypeD Micro HDMI terminal
Input terminal
RGB input Mini Dsub 15P connector female×１
HDMI input Type A Standard HDMI terminal
USB interface
USB2.0 High Speed、Full Speed compliant
USB VIDEO CLASS Ver.1.1compliant
Type Mini B receptacle ×１
Memory interface
SD card slot×１
Main Camera
Item
Specifications
Lens
F2.9
Camera
Frame rate /
Shooting area
Frame
rate
Max.
Min.
1080i
30fps
342mm
192mm
42.75mm
24mm
1080p
15fps
342mm
192mm
42.75mm
24mm
720p
60fps
214mm
120mm
26.75mm
15mm
720p
30fps
342mm
192mm
42.75mm
24mm
WXGA
20fps
342mm
214mm
42.75mm
26.75mm
XGA
20fps
342mm
257mm
42.75mm
32.125mm
VGA
20fps
342mm
257mm
42.75mm
32.125mm

Elmo MO-1 Specifications

General

Product color	Pink
Built-in microphone	Yes
Sensor type	CMOS
White balance	Auto, Manual
Optical sensor size	1/3.2 \
Effective sensor resolution	5 MP
Supported graphics resolutions	-
Digital zoom	8 x
Shooting area (WxD)	257 x 342 mm
VGA (D-Sub) input ports	1
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Cables included	AC, USB

Weight and Dimensions

Depth	226 mm
Width	101 mm
Height	338 mm
Weight	550 g
Dimensions folded (WxDxH)	101 x 226 x 28 mm
